12
3/8-16 X .625 SBHS, STAINLESS STEEL
1B-7189-00
QTY.4
29
HARDWARE NEEDED (ACTUAL SIZE)
2
3
KEEP CHILDREN AWAY FROM THE ASSEMBLY AREA.
TWO CAPABLE ADULTS ARE NEEDED FOR THE
FOLLOWING STEPS.
TOOLS NEEDED
7/32”
Packed in hardware kit.
29
USE 7/32” HEX KEY WRENCH TO INSERT 4 SIDE
BUTTON HEAD SCREWS (#29). TIGHTEN
SCREWS COMPLETELY AT THIS TIME.
NOTE
29
To Next Page
