P R E - A S S E M B L Y T I P S
P R E - A S S E M B L Y T I P S
1. Read this manual carefully before starting assembly. Read each step completely before beginning each step.
2. Some smaller parts may be shipped inside larger parts. Check inside all parts and cartons before assembling or ordering
parts.
3. To make assembly easier, use the Hardware Identifier on page 7-9 to identify and sort all fasteners. Check all cartons for
kits. All hardware may not be located in one kit.
4. Do not tighten hardware until instructed to do so. If hardware is tightened too soon, mounting holes may not align and
parts may not easily fit together. Leave locknuts slightly loose until you are instructed to tighten them.
5. Save these instructions and your proof of purchase (receipt) in the event that the manufacturer has to be contacted for
replacement parts.
2
2L-7910-00
11 - 80 lb. bags of concrete
1 - Post hole digger (optional)
1 - wheel barrow
1 - Concrete form (see note after step 2)
ITEMS NEEDED (NOT INCLUDED)
1 - 15/16" Open end Wrench
1 - 15/16” Socket and Ratchet (optional)
1 - 9/16” Deep Well Socket & Ratchet
1 - 3/4” Socket and Ratchet (optional)
1 - 3/4” Open end Wrench
1 - Phillips Screwdriver
1 - Level
1 - Tape Measure
1 - Rubber Mallet
1 - Set of Padded
Saw Horses
1 - 9/16” Open end Wrench
1 - Cordless drill & 9/64” drill bit
1 - Safety glasses
1 - Ladder
2 - 7/16” Open end Wrench or 1 open end wrench & adjustable wrench
1 - garden hose
1 - 1/2” Socket & Ratchet (optional)
1 - 1/2” Open end Wrench
1 - 5/16” socket driver for cordless drill (used to assemble Board Pads)
1 - 7/32” Hex Key (included)
2020 Escalade Sports
WARNING
FAILURE TO FOLLOW THESE WARNINGS MAY
R E S U L T I N S E R I O U S I N J U RY A N D / O R
PROPERTY DAMAGE.
Owner must ensure that all players know and
follow these rules for safe operation of the system.
! Do not climb on the basketball stand;
! Do not hang on the rim/basket;
! Not intended for basketball games with
competitive character, only suitable for
practice of throwing techniques
! Install only on flat solid ground;
! Do not use in extreme wind or bad weather, the
basketball stand could tip over!
Contact HAMMER SPORT AG at:
Tel:
E-mail: info@hammer-basketball.com
0731-97488-41
Please Do Not Return This Product To The Store!
Hammer Sport AG
Abt. Kundendienst
Von-Liebig-Str. 21
89231 Neu-Ulm
