P A R T S L I S T ( N O T A C T U A L S I Z E )
ACTUATOR CAP
3M-8941-00
QTY. 1
PIVOT TUBE
8S-6658-00
QTY. 1
POST EAR
2S-6795-02
QTY. 2
HEIGHT DECAL
4L-8697-00
QTY. 1
ACTUATOR
4A-6605-00
QTY. 1
ACTUATOR SLEEVE
3M-6542-00
QTY. 1
BOARD PAD, RH
3M-6580-00
QTY. 1
BOARD PAD, LH
3M-6581-00
QTY. 1
TUBE PLUG, 4" SQUARE
3M-6850-00
QTY. 1
PULL PIN
7B-6255-00
QTY. 1
10
11
12
15
14
16
17
18
19
20
(Pre-assembled to part #12)
(Pre-assembled to part #12) (Pre-assembled to part #3)
ACTUATOR HANDLE
4A-6606-00
QTY. 1
13
53
POST PAD
3M-8960-00
QTY. 1
(Packed with the owner’s manual)
(Packed together
with parts #6,8 & 9)
(Packed in hardware kit)
(Packed with actuator handle)
