Goobay 67140 User Manual

8
User‘s Manual
Content: Page:
1 Description and Function 8
2 Intended Use 8
3 Notes on Safety 8
4 Parts Package 9
5 Construction 9
6 Connecting 10
7 Operating 10
8 Care, Maintenance, Storage and transport 11
9 Troubleshooting 11
10 Specications 12
11 Warranty and Liability 12
12 Note on Waste Disposal 12
13 CE Declaration 13
1 Description and Function:
Use your SAT FINDER to adjust your satellite dish for optimized reception. The
SAT FINDER shows the siganl strength in the display.
67000 has an illuminative display.
67140 is micro processor controlled and generates an acoustic signal in
addition for increasing signals. The SAT FINDER is microprocessor controlled
and shows the signal strength of the satellite in its LC display.
2 Intended Use:
Your product is provided for using like described in chapter 1 only. It
is not allowed to use the device in other ways than described in
chapter “Description and Function”. Use this device only in dry
interior rooms. The symbol with the house reminds you of that. If
you do not attend to these regulations and notes on safety, it might causes fatal
accidents, injuries and damages to persons and property.
3 Notes on Safety:
ATTENTION! Only skilled electricians may assemble and disassemble the
housing of the product. There is a risk of electric shock and short circuit!
ATTENTION! Please read the user manualcompletely and carefully. It is
part of the product and includes important information for proper instal-
lation and use. Keep this guide to have it available, when there are uncer-
tainties, or the product will be passed on.
SAT FINDERs
Models: 67000 and 67140

Goobay 67140 Specifications

General

Gain	60 dB
Product color	Black, Silver
Gain (return path)	-10 dB
Gain (forward path)	-40 dB
Sustainability certificates	CE, RoHS
Frequency range (forward path)	950 - 2150 MHz
Connector(s)	F
Ports quantity	2
Quantity	1
Input voltage	13 - 18 V
Power source type	Coaxial cable
Package type	Box
Operating temperature (T-T)	0 - 40 °C

Weight and Dimensions

Depth	68 mm
Width	128 mm
Height	28 mm
Weight	192 g
