26
HEATING PERFORMANCE DATA
PERFORMANCE TEST
All data based upon listed indoor dry bulb temperature. .00 inches external static pressure on coil of outdoor section. Indoor
air cubic feet per minute (CFM) as listed in the Performance Data Sheets:
If conditions vary from this, results will change as follows:
1. As indoor dry bulb temperatures increase, a slight increase will occur in indoor air temperature drop (Delta T). Low
and high side pressures and power will not change.
2. As indoor CFM decreases, a slight increase will occur in indoor temperature drop (Delta T). A slight decrease will
occur in low and high side pressures and power.
A properly operating unit should be within plus or minus 3 degrees of the typical (Delta T) value shown.
A properly operating unit should be within plus or minus 7 PSIG of the HI PR shown.
A properly operating unit should be within plus or minus 3 PSIG of the LO PR shown.
A properly operating unit should be within plus or minus 3 Amps of the typical value shown.
GPH13[48-60]M41*
EXPANDED PERFORMANCE DAT
MODEL: GPH1348M41* HEATING OPERATION
Outdoor Ambient Temperature
65 60 55 50 47 45 40 35 30 25 20 17 15 10 5 -5 -10
MBh 57.2 54.1 51.0 47.6 45.5 44.1 41.0 37.8 32.8 30.2 27.8 26.3 25.3 22.7 20.1 17.6 15.0 12.3
Delta T 30.8 29.1 27.4 25.6 24.5 23.7 22.0 20.3 17.6 16.3 15.0 14.2 13.6 12.2 10.8 9.5 8.1 6.6
KW 3.90 3.83 3.75 3.68 3.63 3.60 3.53 3.46 2.48 2.43 2.38 2.36 2.34 2.29 2.24 2.19 2.14 2.09
AMPS 19.0 17.7 16.7 15.8 15.3 15.0 14.3 13.7 13.1 12.6 12.1 11.9 11.8 11.2 10.6 10.1 9.5 8.7
COP 4.29 4.14 3.97 3.79 3.66 3.58 3.39 3.20 3.86 3.64 3.42 3.27 3.17 2.91 2.63 2.35 2.05 1.72
EER 14.7 14.1 13.6 13.0 12.5 12.2 11.6 10.9 13.2 12.4 11.7 11.2 10.8 9.9 9.0 8.0 7.0 5.9
HI PR 372 357 343 328 320 314 302 290 278 265 255 249 244 235 226 217 209 202
LO PR 130 121 113 104 98 95 87 77 70 62 55 51 49 42 36 30 26 21
Above information is for nominal CFM and 70 degree indoor dry bulb. Instantaneous capacity listed.
MODEL: GPH1360M41* HEATING OPERATION
Outdoor Ambient Temperature
65 60 55 50 47 45 40 35 30 25 20 17 15 10 5 -5 -10
MBh 69.8 66.0 62.2 58.1 55.5 53.8 50.0 46.1 39.1 36.1 33.3 31.4 30.3 27.1 24.1 21.0 17.9 14.7
Delta T 35.9 34.0 32.0 29.9 28.5 27.7 25.7 23.7 20.1 18.6 17.1 16.2 15.6 14.0 12.4 10.8 9.2 7.5
KW 4.80 4.71 4.62 4.53 4.47 4.44 4.35 4.26 2.41 2.36 2.32 2.30 2.28 2.24 2.20 2.16 2.12 2.08
AMPS 24.1 22.5 21.2 20.1 19.4 19.1 18.1 17.3 16.7 16.0 15.4 15.0 14.9 14.2 13.4 12.8 12.0 11.0
COP 4.25 4.10 3.94 3.76 3.63 3.55 3.36 3.17 4.76 4.47 4.19 4.00 3.88 3.54 3.20 2.84 2.47 2.06
EER 14.5 14.0 13.5 12.8 12.4 12.1 11.5 10.8 16.3 15.3 14.3 13.7 13.2 12.1 10.9 9.7 8.4 7.1
HI PR 385 369 354 339 331 325 312 300 287 274 263 257 252 243 233 224 216 208
LO PR 134 124 116 107 101 97 89 80 72 64 56 52 50 43 37 31 27 21
Above information is for nominal CFM and 70 degree indoor dry bulb. Instantaneous capacity listed.
