Product sPecifications
Product sPecifications
SS-GPH14H www.goodmanmfg.com 3
sPecifications
GPH14
24H41A*
GPH14
30H41A*
GPH14
36H41A*
GPH14
42H41A*
GPH14
48H41A*
GPH14
60H41A*
CoolinG CAPACity
AHRI Cooling Capacity (BTU/h) 24,000 28,400 36,000 40,500 46,000 57,000
Sensible BTU/h 18,200 23,400 27,400 29,600 35,400 40,500
SEER / EER 14.5 / 12.0 14.0 / 12.0 14.0 / 11.5 14.0 / 12.0 14.0 / 12.0 14.0 / 12
Decibels 76 76 78 78 80 80
AHRI Numbers 4385132 4385133 4385134 4385135 4385136 4385137
HeAtinG CAPACity
BTU/h (47°F) 22,800 27,600 32,200 37,600 44,000 54,500
C.O.P. (47°F) 3.8 3.8 3.7 3.8 3.8 3.6
BTU/h (17°F) 13,000 15,400 20,400 21,600 26,000 33,800
C.O.P. (17°F) 2.4 2.5 2.4 2.4 2.4 2.5
HSPF 8.0 8.0 8.0 8.0 8.0 8.0
evAPorAtor Motor
Type EEM EEM EEM EEM EEM EEM
Wheel (D x W) 10 x 8 10 x 8 10 x 8 10 x 8 10 x 8 11 x 8
Cooling CFM 875 1,050 1,200 1,300 1,600 1,700
Fan-Only CFM 800 950 1,100 1,200 1,400 1,600
RLA 1.5 1.86 1.86 2.9 2.9 2.9
No. of Speeds 5 5 5 5 5 5
Horsepower - RPM ½ - 1,050 ½ - 1,050 ½ - 1,050 ½ - 1,050 ¾ - 1,050 ¾ - 1,050
evAPorAtor Coil
Face Area (ft
2
) 5.25 4.67 5.2 6.2 6.2 7.0
Rows Deep/ Fins per Inch 3/ 16 4/ 16 3/ 14 4/ 14 4/ 14 4/ 14
Indoor Metering Device Size 0.057 0.065 0.068 0.072 0.076 0.088
Filter Size (ft
2
) 20 x 20 x 1 20 x 25 x 1 25 x 25 x 1 (2) 20 x 20 x 1 (2) 20 x 20 x 1 (2) 20 x 25 x 1
Drain Size (NPT) ¾" ¾" ¾" ¾" ¾" ¾"
Refrigerant Charge (oz.) 85 105 125 150 190 200
Condenser FAn / Coil
Horsepower - RPM 1/6 - 815 1/6 - 815 ¼ - 1075 ¼ - 1075 ¼ - 1075 ¼ - 1075
RLA/LRA 1.1 / 1.7 1.1 / 1.7 1.5 /3.0 1.4 / 2.9 1.4 / 2.9 1.4 / 2.9
Fan Diameter / # Fan Blades 22 / 3 22 / 3 22 / 4 22 / 4 22 / 4 22 / 4
Face Area (ft
2
) 13.4 13.4 17 17 19.1 19.1
Outdoor Metering Device Size 0.049 0.047 0.067 0.065 0.065 0.071
Rows Deep/ Fins per Inch 1 / 24 1 / 24 1 / 24 1 / 24 2 / 16 2 / 16
CoMPressor
Quantity 1 1 1 1 1 1
Type Scroll Scroll Scroll Scroll Scroll Scroll
Stage Single Single Single Single Single Single
eleCtriCAl dAtA
Voltage/Phase/ Frequency 208-230/1/60 208-230/1/60 208-230/1/60 208-230/1/60 208-230/1/60 208-230/1/60
Compressor RLA/LRA 12.8 / 58.3 14.1 / 73 16.7 / 79 17.9 / 112 19.9 / 109 26.4 / 134
Indoor Blower FLA 1.5 1.86 1.86 2.9 2.9 2.9
Outdoor Fan RLA 1.1 1.1 1.4 1.4 1.4 1.4
Total Unit Amps 15.4 17.06 19.96 22.2 24.2 30.7
Min. Circuit Ampacity¹ 18.6 20.6 24.2 26.6 29.2 40.2
Min. Overcurrent Protection (amps)² 30 30 40 40 45 60
sHiP WeiGHt (lbs)
325 325 385 385 415 415
oPerAtinG WeiGHt (lbs)
315 315 375 375 405 405
¹ Wire size should be determined in accordance with Naonal Electrical Codes. Extensive wire runs will require larger wire sizes.
² Must use me-delay fuses or HACR-type circuit breakers of the same size as noted.
Note: Always check the S&R plate for electrical data on the unit being installed.
