5
HEAT PUMP SPECIFICATIONS GSH14[018-060]1A*
(1)
Wire size should be determined in acordance with National Electrical Codes. Extensive wire runs will require larger wire sizes.
(2)
May use fuses or HACR type Circuit Breakers of the same size as noted.
NOTE: This data is provided as a guide, it is important to electrically connect the unit and properly size fuses/
circuit breakers and wires in accordance with all national and/or local electrical codes. Use copper wire only.
GSH140181A*
GSH140241A*
GSH140301A*
GSH140361A*
GSH140421A*
GSH140481A*
GSH140601A*
Cooling Capacity, BTUH 18,000 24,000 28,000 34,600 39,600 46,000 55,000
Compressor
R.L. Amps 9 10.9 12.2 13.4 16 18.3 19.8
L.R. Amps 41.0 54.0 63.0 73.0 88.0 109.0 137.0
Loss of Charge Pressure Switch
Open / Close 7 PSIG/25 PSIG 7 PSIG/25 PSIG 7 PSIG/25 PSIG 7 PSIG/25 PSIG 7PSIG/25 PSIG 7 PSIG/25 PSIG 7PSIG/25 PSIG
Condenser Fan Motor
Horsepower 1/12 1/6 1/6 1/4 1/4 1/4 1/4
F.L. Amps 0.6 1.1 1.1 1.5 1.5 1.5 1.5
Liquid Line, Inches O.D. 3/8" 3/8" 3/8" 3/8" 3/8" 3/8" 3/8"
Suction Line, Inches O.D. 3/4" 3/4" 3/4" 7/8" 7/8" 7/8" 7/8"
Refrigerant Charge 160 160 165 220 220 280 285
Power Supply 208/230-60-1 208/230-60-1 208/230-60-1 208/230-60-1 208/230-60-1 208/230-60-1 208/230-60-1
Minimum Circuit Ampacit
(1)
11.8 14.7 16.3 18.3 21.5 27.8 27.3
Maximum Overcurrent Device
(2)
20 20 20 30 30 40 40
Electrical Conduit Size
Power Supply (Inches) 1/2 or 3/4 1/2 or 3/4 1/2 or 3/4 1/2 or 3/4 1/2 or 3/4 1/2 or 3/4 1/2 or 3/4
Approximate Shipping Weight 199 207 207 242 242 266 280
