Goodman SSX140361B Series User Manual

CONDENSING UNIT SPECIFICATIONS
6
NOTE: This data is provided as a guide, it is important to electrically connect the unit and properly size fuses/
circuit breakers and wires in accordance with all national and/or local electrical codes. Use copper wire only.
SSX140181A* - SSX140361A*
*
Up to 24' in equivalent line length
(1)
Wire size should be determined in accordance with National Electrical Codes; extensive wire runs will require larger wire sizes.
(2)
Maximum Overcurrent Protection Device: MUST use Time Delay Fuses or HACR type Circuit Breaker of the same size as noted.
SSX140421A* - SSX140601A*
SSX14018
AA/AB
SSX14018
AC
SSX14024
AA/AB
SSX140241
AC
SSX140301
AA/AB/AC
SSX140301
AD/AE
SSX140361
AA/AB/AC
SSX140361
AD/AE
Cooling Capacity, BTUH 18,000 18,000 24,000 24,000 30,000 30,000 36,000 36,000
Compressor
R.L. Amps 9.00 9.00 13.4 13.4 12.8 12.8 14.1 14.1
L.R. Amps 48.0 48.0 58.3 58.3 64.0 64.0 77.0 77.0
Low Pressure Switch
Open
Close
22 PSIG
50 PSIG
22 PSIG
50 PSIG
22 PSIG
50 PSIG
22 PSIG
50 PSIG
22 PSIG
50 PSIG
22 PSIG
50 PSIG
22 PSIG
50 PSIG
22 PSIG
50 PSIG
High Pressure Switch
Open
Close
610 PSIG
420 PSIG
610 PSIG
420 PSIG
610 PSIG
420 PSIG
610 PSIG
420 PSIG
610 PSIG
420 PSIG
610 PSIG
420 PSIG
610 PSIG
420 PSIG
610 PSIG
420 PSIG
Condenser Fan Motor
Horsepower 1/12 1/12 1/12 1/12 1/6 1/6 1/4 1/4
F.L. Amps 0.6 0.6 0.6 0.6 1.5 1.5 1.6 1.6
Liquid Line, Inches O.D.* 3/8"3/8"3/8"3/8"3/8"3/8"3/8"3/8"
Suction Line, Inches O.D.* 3/4"3/4"3/4"3/4"3/4"3/4"7/8"7/8"
Refrigerant Charge 130.0 121.0 135.0 126.0 140.0 131.0 155.0 146.0
Power Supply 208/230-60-1 208/230-60-1 208/230-60-1 208/230-60-1 208/230-60-1 208/230-60-1 208/230-60-1 208/230-60-1
Minimum Circuit Ampacity
(1)
11.8 11.8 17.4 17.4 17.5 17.5 19.2 19.2
Maximum Overcurrent Device
(2)
20 20 30 30 30 30 30 30
Electrical Conduit Size
Power Supply (Inches) 1/2 or 3/4 1/2 or 3/4 1/2 or 3/4 1/2 or 3/4 1/2 or 3/4 1/2 or 3/4 1/2 or 3/4 1/2 or 3/4
Approximate Shipping Weight 178 178 178 178 195 195 199 199
SSX140421
AA/AB/AC
SSX140421
AD/AE
SSX140481
AA/AB/AC
SSX140481
AD/AE
SSX140601
AA/AB/AC
SSX140601
AD/AE
Cooling Capacity, BTUH 42,000 42,000 48,000 48,000 60,000 60,000
Compressor
R.L. Amps
17.9 17.9 19.8 19.8 26.4 26.4
L.R. Amps
112.0 112.0 109.0 109.0 134.0 134.0
Low Pressure Switch
Open
Close
22 PSIG
50 PSIG
22 PSIG
50 PSIG
22 PSIG
50 PSIG
22 PSIG
50 PSIG
22 PSIG
50 PSIG
22 PSIG
50 PSIG
High Pressure Switch
Open
Close
610 PSIG
420 PSIG
610 PSIG
420 PSIG
610 PSIG
420 PSIG
610 PSIG
420 PSIG
610 PSIG
420 PSIG
610 PSIG
420 PSIG
Condenser Fan Motor
Horsepower 1/4 1/4 1/4 1/4 1/4 1/4
F.L. Amps 1.6 1.6 1.6 1.6 1.6 1.6
Liquid Line, Inches O.D.* 3/8" 3/8" 3/8" 3/8" 3/8" 3/8"
Suction Line, Inches O.D.* 7/8" 7/8" 7/8" 7/8" 7/8" 7/8"
Refrigerant Charge
180.0 174.0 195.0 186.0 280.0 271.0
Power Supply 208/230-60-1 208/230-60-1 208/230-60-1 208/230-60-1 208/230-60-1 208/230-60-1
Minimum Circuit Am
p
acit
y
(1)
24.0 24.0 26.4 26.4 34.6 34.6
Maximum Overcurrent Device
(2 )
40 40 40 40 60 60
Electrical Conduit Size
Power Supply (Inches) 1/2 or 3/4 1/2 or 3/4 1/2 or 3/4 1/2 or 3/4 1/2 or 3/4 1/2 or 3/4
Approximate Shipping Weight
207 207 242 242 280 280
