8
COOLING PERFORMANCE DATA
SSX140181A*
EXPANDED PERFORMANCE DATA
COOLING OPERATION
MODEL: SSX140181A* / CA*F3131B6A* + TXV, Design Subcooling @ ARI 95°F Conditions, 7° - 9°F @ the Serv. Vlv.
Outdoor Ambient Temperature
65 75 85 95 105 115
Entering Indoor Wet Bulb Temperature
IDB*Airflow 596367715963677159636771596367715963677159636771
MBh 17.6 18.3 20.0 - 17.2 17.9 19.6 - 16.8 17.4 19.1 - 16.4 17.0 18.6 - 15.6 16.2 17.7 - 14.4 15.0 16.4 -
S/T 0.71 0.59 0.41 - 0.74 0.62 0.43 - 0.76 0.63 0.44 - 0.78 0.65 0.45 - 0.81 0.68 0.47 - 0.82 0.68 0.47 -
Delta T171511 - 171511 - 171511 - 171511 - 171511 - 161411 -
676 KW 1.27 1.30 1.33 - 1.36 1.39 1.43 - 1.44 1.47 1.51 - 1.51 1.54 1.59 - 1.57 1.60 1.65 - 1.62 1.65 1.70 -
AMPS 4.4 4.5 4.6 - 4.7 4.8 5.0 - 5.1 5.2 5.4 - 5.5 5.6 5.8 - 5.8 5.9 6.1 - 6.1 6.3 6.5 -
HI PR 226 243 246 - 255 274 278 - 290 312 316 - 330 355 360 - 372 400 405 - 416 448 454 -
LO PR 116 120 131 - 119 123 135 - 124 127 139 - 127 131 143 - 129 133 146 - 133 137 149 -
MBh 17.1 17.7 19.4 - 16.7 17.3 19.0 - 16.3 16.9 18.5 - 15.9 16.5 18.1 - 15.1 15.7 17.2 - 14.0 14.5 15.9 -
S/T 0.68 0.57 0.39 - 0.70 0.59 0.41 - 0.72 0.60 0.42 - 0.74 0.62 0.43 - 0.77 0.65 0.45 - 0.78 0.65 0.45 -
Delta T181512 - 181612 - 181612 - 181612 - 181512 - 171411 -
70 601 KW 1.26 1.29 1.32 - 1.35 1.38 1.42 - 1.43 1.46 1.50 - 1.50 1.53 1.57 - 1.55 1.59 1.63 - 1.60 1.64 1.69 -
AMPS 4.3 4.4 4.6 - 4.7 4.8 4.9 - 5.1 5.2 5.4 - 5.4 5.5 5.7 - 5.7 5.9 6.1 - 6.1 6.2 6.4 -
HI PR 223 240 244 - 253 272 275 - 287 309 313 - 327 352 357 - 368 396 401 - 412 443 450 -
LO PR 115 119 129 - 118 122 133 - 122 126 138 - 126 130 141 - 128 132 144 - 131 135 148 -
MBh 15.8 16.4 17.9 - 15.4 16.0 17.5 - 15.1 15.6 17.1 - 14.7 15.2 16.7 - 14.0 14.5 15.9 - 12.9 13.4 14.7 -
S/T 0.65 0.55 0.38 - 0.68 0.57 0.39 - 0.70 0.58 0.40 - 0.72 0.60 0.42 - 0.75 0.62 0.43 - 0.75 0.63 0.43 -
Delta T181612 - 181612 - 181612 - 181612 - 181612 - 171511 -
526 KW 1.25 1.28 1.31 - 1.34 1.37 1.41 - 1.42 1.45 1.49 - 1.49 1.52 1.56 - 1.54 1.57 1.62 - 1.59 1.62 1.67 -
AMPS 4.3 4.4 4.5 - 4.6 4.7 4.9 - 5.0 5.1 5.3 - 5.4 5.5 5.7 - 5.7 5.8 6.0 - 6.0 6.2 6.4 -
HI PR 221 238 241 - 250 269 273 - 284 306 310 - 324 348 353 - 364 392 397 - 408 439 445 -
LO PR 114 117 128 - 117 121 132 - 121 125 136 - 124 128 140 - 127 131 143 - 130 134 146 -
MBh 17.9 18.5 20.0 21.5 17.5 18.0 19.5 21.0 17.1 17.6 19.1 20.5 16.7 17.2 18.6 20.0 15.9 16.3 17.7 19.0 14.7 15.1 16.4 17.6
S/T 0.810.720.550.350.840.750.570.370.860.770.580.370.890.79 0.60 0.39 0.92 0.82 0.62 0.40 0.93 0.83 0.63 0.40
Delta T2018151020181510201815102019 15 10 20 18 15 10 19 17 14 10
676 KW 1.271.301.331.371.361.391.431.471.441.471.511.561.511.54 1.59 1.63 1.57 1.60 1.65 1.70 1.62 1.65 1.70 1.76
AMPS4.44.54.64.84.74.85.05.25.15.25.45.65.5
5.6
5.8 6.0 5.8 5.9 6.1 6.4 6.1 6.3 6.5 6.7
HI PR 226 243 246 252 255 274 278 284 290 312 316 323 330 355 360 368 372 400 405 414 416 448 454 464
LO PR 116 120 131 139 119 123 135 143 124 127 139 148 127 131 143 152 129 133 146 155 133 137 149 159
MBh 17.4 17.9 19.4 20.8 17.0 17.5 19.0 20.3 16.6 17.1 18.5 19.9 16.2 16.7 18.1 19.4 15.4 15.8 17.2 18.4 14.3 14.7 15.9 17.1
S/T 0.770.690.520.340.800.720.540.350.820.730.560.360.850.76 0.57 0.37 0.88 0.79 0.59 0.38 0.89 0.79 0.60 0.39
Delta T2119161121191611211916112119 16 11 21 19 16 11 19 18 15 10
75 601 KW 1.261.291.321.361.351.381.421.461.431.461.501.551.501.53 1.57 1.62 1.55 1.59 1.63 1.69 1.60 1.64 1.69 1.74
AMPS4.34.44.64.74.74.84.95.15.15.25.45.65.4
5.5
5.7 5.9 5.7 5.9 6.1 6.3 6.1 6.2 6.4 6.7
HI PR 223 240 244 249 253 272 275 282 287 309 313 320 327 352 357 365 368 396 401 410 412 443 450 459
LO PR 115 119 129 138 118 122 133 142 122 126 138 147 126 130 141 151 128 132 144 154 131 135 148 157
MBh 16.1 16.5 17.9 19.2 15.7 16.2 17.5 18.8 15.3 15.8 17.1 18.3 15.0 15.4 16.7 17.9 14.2 14.6 15.8 17.0 13.2 13.5 14.7 15.7
S/T 0.740.670.500.320.770.690.520.340.790.710.540.340.820.73 0.55 0.36 0.85 0.76 0.57 0.37 0.85 0.76 0.58 0.37
Delta T2119161121191611212016112120 16 11 21 19 16 11 20 18 15 10
526 KW 1.251.281.311.351.341.371.411.451.421.451.491.531.491.52 1.56 1.61 1.54 1.57 1.62 1.67 1.59 1.62 1.67 1.73
AMPS4.34.44.54.74.64.74.95.15.05.15.35.55.4
5.5
5.7 5.9 5.7 5.8 6.0 6.3 6.0 6.2 6.4 6.6
HI PR 221 238 241 247 250 269 273 279 284 306 310 317 324
348
353 361 364 392 397 406 408 439 445 455
LO PR 114 117 128 136 117 121 132 140 121 125 136 145 124 128 140 149 127 131 143 152 130 134 146 156
* Entering Indoor Dry Bulb Temperature NOTE: Shaded area is ACCA (TVA) conditions
