38
PERFORMANCE DATA
PERFORMANCE TEST
All data based upon listed indoor dry bulb temperature. .00 inches external static pressure on coil of outdoor section. Indoor
air cubic feet per minute (CFM) as listed in the Performance Data Sheets:
If conditions vary from this, results will change as follows:
1. As indoor dry bulb temperatures increase, a slight increase will occur in indoor air temperature drop (Delta T). Low and
high side pressures and power will not change.
2. As indoor CFM decreases, a slight increase will occur in indoor temperature drop (Delta T). A slight decrease will
occur in low and high side pressures and power.
A properly operating unit should be within plus or minus 2 degrees of the subcooling value shown in the installation
instructions.
A properly operating unit should be within plus or minus 3 degrees of the typical (Delta T) value shown.
A properly operating unit should be within plus or minus 10 PSIG of the HI PR shown.
A properly operating unit should be within plus or minus 5 PSIG of the LO PR shown.
A properly operating unit should be within plus or minus 3 Amps of the typical value shown.
NOTE: Pressures are measures at the liquid and suction service valve ports.
SSX140421C*
Outdoor
Temp. ° F.
Total
Bt u h
Sensible
Btuh
Latent
Btuh
Total
Watts
75° 42,116 29,985 12,131 2,950
80° 41,614 30,004 11,610 3,040
85° 41,113 30,015 11,098 3,130
90° 40,611 30,127 10,485 3,205
95° 40,110 30,227 9,883 3,280
100° 39,107 30,029 9,078 3,350
105° 38,105 29,803 8,301 3,420
110° 36,701 28,826 7,875 3,475
115° 35,297 27,839 7,458 3,530
95° 37,200 30,132 7,068 3,160
TVA Conditions @ 95° OD DB, 75° ID DB 63° ID WB
MODEL: SSX140421C* / CA*F4860*6B* W/.070 Orifice,
Conditions: 80°F IDB, 67°F IWB @ 1450 CFM
