Goodmans GCE7356MP3 - Wiring Identification

L-CHR-CH
ANTENNA SOCKET
ANTENNA
CABLE
REAR LINE OUT
GREY
WHITE
RED
RCA-TO-RCA CABLES
(not supplied)
(Not Supplied)
FEMALE WITH MALE TERMINAL
ISO CONNECTOR 4PIN+8PIN
CONNECTOR B
Figure 2
CONNECTOR A
7 87 8
1 2
3 4
5 65
3
1
6
4
2
ISO CONNECTOR WIRING CHART
PIN
WIRE COLOR
FUNCTION / LABEL
A4
A5
A7
A8
B1
B2
B3
B4
B5
B6
B7
B8
YELLOW
BLUE
RED
BLACK
VIOLET
VIOLET / BLACK
GREY
GREY / BLACK
WHITE
WHITE / BLACK
GREEN
GREEN / BLACK
BATTERY (+)
POWER ANTENNA
IGNITION(ACC)
GROUND
RIGHT REAR SPEAKER (+)
RIGHT REAR SPEAKER (-)
RIGHT FRONT SPEAKER (+)
RIGHT FRONT SPEAKER (-)
LEFT FRONT SPEAKER (+)
LEFT FRONT SPEAKER (-)
LEFT REAR SPEAKER (+)
LEFT REAR SPEAKER (-)
ISO
CONNECTOR
(See Figure 2)
FUSE
20-PIN
AUDIO/POWER
HARNESS
AMP
YELLOW
RED
(RED)
Ignition wire
(YELLOW)
Battery wire
7
WIRING IDENTIFICATION
03
