Google Nest Protect - Placement on the Ceiling or Wall

60 cm
Maximum
15 cm
Minimum
BEST
ON CEILING
30 cm
Minimum
OKAY
ON WALL
Figure 1
Figure 2
Figure 3
ANYWHERE IN
THIS AREA
ANYWHERE IN
THIS AREA
90 cm
90 cm
11
Placement on the ceiling or wall
Installation on the ceiling is recommended. Use the
back plate as a guide to mark where the screws
will go. Make sure that it’s at least 30 cm (12 inches)
away from the wall.
Placement on a sloping ceiling
If you have a sloping, pitched or cathedral
ceiling, Nest Protect should be 90 cm (35 inches)
from the highest peak.
