Additional components supplied for use with Gooligum baseline, mid-range and introductory enhanced
mid-range PIC tutorials
Qty
Description
1
PIC10F200-I/P MCU
1
PIC12F509-I/P MCU
1
PIC12F629-I/P MCU
1
PIC12F1501-I/P MCU
1
PIC16F506-I/P MCU
1
PIC16F684-I/P MCU
1
PIC16F1824-I/P MCU
1
1 nF ceramic capacitor
1
100 nF ceramic capacitor
2
1 µF ceramic capacitor
1
100 Ω 5% 1/4W resistor
1
1 kΩ 5% 1/4W resistor
1
4.7 kΩ 5% 1/4W resistor
2
6.8 kΩ 5% 1/4W resistor
2
10 kΩ 5% 1/4W resistors
2
22 kΩ 5% 1/4W resistors
2
100 kΩ 5% 1/4W resistors
2
1N4148 diodes
1
74HC14N hex Schmitt-trigger inverter
2
CDS photocells (LDRs), 20-60 kΩ when illuminated
1
PCB-mount pushbutton switch
