5 – 2. Brightness

The screen brightness can be changed in the "BRIGHTNESS" menu. The intensity of the PADs is fixed.

6 – THE TRACK NAMING PROTOCOL

You can display on the screen of the LIO BOX, the information of BPM, tone and duration of the track. You just

have to indicate them in the name of the track according to the following protocol:

If you don’t want to indicate a value, you must leave the field empty and not put a "; ".

If you don’t want to display a track on the box, all you have to do is add the prefix "()".

Example: "() Track number 1"

7 – USE OF LIOBOX

7 – 1. Navigation

Access to the LIO BOX settings is via the "MENU" button. Navigation is then performed using the click wheel.

When you are in the menus, the "BACK" button return to the previous menu and the "MENU" button return

to the main screen.

7 – 2. Track lanch

You have two possibilities to launch the tracks. Either by using the "PLAY" button, to launch the next selected

track. By default the next selected track is the next track of the show.

Either by using the click of the wheel, which makes it possible to select the next track by turning the wheel

and to launch it by clicking on it.

When you launch a track from the LIOBOX, a countdown of the remaining time is triggered. This time is

indicative and corresponds to the time you will have entered in the title, according to the naming procedure.

7 – 3. Refresh

Although the LIO BOX is continuously updated automatically in the event of modification of the Ableton

session, you can do a manual refresh thanks to the menu « REFRESH ».

7 – 4. Position of the track in the session / Setlist

The position of the current track in the set or setlist is displayed at the top of the screen.
