Gorenje GV62110 User Manual

3
Installation of aesthetic panel
【Figure
4a】
2 Install the hook on the aesthetic wooden panel and put the hook into the slot of the outer door of
dishwasher(see figure 4a). After positioning of the panel, fix the panel onto the outer door by
screws and bolts(See Figure 4b) .
Installation of aesthetic
wooden panel
【Figure4b】
.takeawaythecover
.pinupthescrew
. get back the cover
1
2
3
Hop hook
St4 countersunk
head screw
Lower hook
Outer door of
dishwasher
Aesthetic panel
Hook for aesthetic panel
4X18 screw
Spacer for aesthetic panel
Cover

Gorenje GV62110 Specifications

General

Brand	Gorenje
Model	GV62110
Category	Dishwasher
Language	English
