GOSSEN METRAWATT GMBH 29
Test Sequence per VDE 0701
Select connection, select test regulation VDE 0701 part 1 or 200, classify the DUT (SC I, II or III), part 1: extension cable X/– (with/without)
Visual inspection
OK?
SC I: RPE
OK?
I
L
OK?
Short-circuit
at DUT?
Test
OK?
Yes/No
No
Yes
Display results, save/print report
Yes
No
Yes
No
No
Test
OK?
Framed with dashed line:
The test is only run if it has been activated in
the initial program window, or in the Setup
menu under Sequence ...
Switch line voltage to test socket, start function test
Start
function test
Safety Class I only: Contact all exposed, conductive parts with the
probe. The test can be repeated as often as desired for various
protective conductor parts with the manual sequence*
* If it is not clear whether or not all
exposed, conductive parts are
connected to one another or to the
protective conductor, testing can be
performed in the manual mode.
Switch DUT on
RISO+I
EL
OK?
or
Yes
No
No
Yes
