GOSSEN METRAWATT GMBH 41
Multimeter Measurements for Devices with Feature F01
Reference Ranges
Line Voltage 230 V ±0.2%
Line Frequency 50 Hz ±0.1%
Waveshape Sine (deviation between effective and rectified
value < 0.5%)
Ambient Temperature +23 °C ±2K
Relative Humidity 40 … 60%
Load Resistance Linear
Nominal Ranges of Use
Line Voltage 207 V … 253 V
Line Frequency 50 Hz
Line Voltage
Waveshape Sine
Temperature
0 °C … +50 °C
Ambient Conditions
Storage Temperature – 20 °C ... + 60 °C
Operating Temperature – 10 °C ... + 50 °C
Accuracy Range 0 °C ... + 50 °C
Relative Humidity Max. 75%, no condensation allowed
Elevation Max. 2000 m
Deployment Indoors, except within specified ambient
conditions
Influencing Quantities and Influence Error
Func-
tion
Measured Quantity Measuring Range /
Nominal Range of
Use
Reso-
lution
Open-
Circuit
Voltage
U
0
Short-
Circuit
Current
I
K
Internal
Resis-
tance
R
I
Measuring
Error
Intrinsic Error Overload Capacity
Value Duration
U
AC/DC
Voltage
0 ... 253.0 V
,
and
0.1 V — — —
—
±(2.5 % rdg. +5 d)
>10d
253 V cont.
Low Voltage, SC III
±(5% rdg. +10 d)
R Resistance 0 ... 150.0 k
Ω 100 Ω <20V– 1.1mA — — ±(1% rdg. +3 d) 253 V cont.
I
Clip
Current with
Clip-On Current-
Voltage Transformer
WZ12C
0.000 ... 10.00 A 1mA — — 1.5MΩ —
±(3% rdg. +10 d)
>10d
without clip-on device
253 V cont.
0 ... 100 A
1A — — 1.5MΩ — 253 V cont.
Temp.
Temperature
with Pt100/Pt1000
Sensor
– 200 ... – 50
°C1°C
<20V– 1.1mA — —
±(2% rdg. +1 °C) 10 V cont.
– 50.1 ... + 300.0
°C0.1°C ±(1% rdg. +1 °C) 10 V cont.
+300 ... +850
°C1°C ±(2% rdg. +1 °C) 10 V cont.
Influencing Quantity /
Sphere of Influence
Designation
per
DIN VDE 0404
Influence Error
± … % of Measured Value
Position Change E1 —
Change in Test Setup Supply Power E2 2.5
Temperature Fluctuation
E3
Specified influence error applies per
10 K change in temperature:
0 … 21
°C and 25 … 40 °C
1 in case of PE measurement
0.5 for all other measuring ranges
Current at Device Under Test E4 2.5
Low-Frequency Magnetic Fields E5 2.5
Impedance at Device Under Test E6 2.5
Capacitance, Insulation Measurement E7 2.5
Waveshape of Measured Current
E8
49 … 51 Hz 2 for capacitive load (for equivalent
leakage current)
45 … 100 Hz 1 (for contact current)
2.5 for all other measuring ranges
