1. Firmly grasp the Tube in one hand. Keep one hand on
the Tube throughout removal process
2. Orient the product so that the Bottom Bracket faces up
3. Secure the Kickstand to the most acute angle setting
4. Locate Tube release hex bolts on the under side of
Bottom Bracket
5. Remove hex bolts using an Allen key (Figure A)
6. Locate clip directly underneath the tail (closed) end
of the tube on the interior of product (Figure B)
7. With a firm grasp on the Tube, release the clip
8. Remove Bottom Bracket (Figure C)
9. Remove Tube from EVA Shell (Figure D)
10. Reverse steps to reassemble
For repairing purposes, the tube can be removed from
the rest of the device with the following procedures:
Tube Removal
• Wear protective gloves when handling broken tube
to avoid risk of injury.
WARNING
