UNPACKING (CONTINUED)
Contents (Continued):
Inspect:
• After unpacking the unit, inspect carefully for any damage that may
have occurred during transit. Check for loose, missing or damaged
parts. Shipping damage claims must be filed with carrier.
• See General Safety Instructions on page 3, and Cautions and
Warnings as shown.
15” - 25” Telescoping Suction Pipe
25” - 40” Extension Pipe
1Figure
(A) Spin Collar
(B) Direct Mount
(H or J)
Dispensing
Hose
(C) Fiber Gasket
(F) Ring Terminals
(K) Reducer
(E) Fuse
Assembly
(D) Tank
Adapter
(L) Suction Pipe Assembly
(G) Wire
Connector
(M) Automatic
Shut-off Nozzle
(N) Manual
Shut-off Nozzle
(P) Lockable
Nozzle Holder
(Q) Standard
Nozzle Holder
GETTING STARTED
SAFETY /
SPECIFICATIONS
ASSEMBLY /
INSTALLATION
OPERATION TROUBLESHOOTING
MAINTENANCE /
REPAIR
2-EN
