SPECIFICATIONS (CONTINUED)
M-150S-EM & -E-PO
M-150S-AU & -MU & -PO
M-180S and M-
240S
Dimensions Inches (cm)
A. Pump Ass’y Width 9.19 (23.34) 9.13 (23.20)
B. Pump Ass’y Height 5.42 (13.77) 4.95 (12.57)
C. Pump Ass’y Height
w/Nozzle Holder
7.00 (17.78) 6.74 (17.12)
D. Direct Mount (NPT
Male) Thread Height
1.00 (2.54) N/A
E. Pump Ass’y Depth 10.45 (26.54) 10.45 (26.54)
Figure 2
M-150S-AU & -MU & -PO
M-180S and M-240S
M-150S-EM & -E-PO
ALL
