GR 100 Series - Page 5

4- Fix the motor on the basement plate with the screws like in the
fig.2
Fig.2
A B Alfa A B Alfa
0 cm 16-20cm 90° 15 cm 16-20cm 90°
0 cm 20-35cm 120° 15 cm 20-25cm 100°
5 cm 16-20cm 90° 15 cm 25-30cm 90°
5 cm 20-25cm 120° 15 cm 30-35cm 100°
5 cm 25-35cm 110° 15 cm 35 cm 90°
10 cm 16-20cm 90° 20 cm 16-35cm 90°
10 cm 20-25cm 110° 25 cm 16-30cm 90°
10 cm 25-30cm 90° 30 cm 20cm 90°
10 cm 30-35cm 100° 35 cm 20cm 90°
