Graco 04540-531 - Crib Assembly Step 3; Attach Crib Ends to Posts; Crib Assembly Step 4; Attach Stretcher Bar

PAGE 8
Continued
Step 3
Step 4
PAGE 8
2
2
4
4
4
4
Attach left crib end(A) and right crib end(B) to the
side(C) using M6*57 Allen head bolts( 2 )&barrel
See figure 3.
left post(A1) and right post(B1) on the back fixed
Figure 3
nuts( 4 ).
A
B
A1
B1
Attach the stretcher bar(P) to the bottom rails of both crib
ends, using Allen head bolts M6*57( 2 ) and barrel
Figure 4
P
2
5
nuts( 4 ).
See figure 4.
4
