Step 6
Fatigue 6
1
1
1
1
5
4
4
Attach front fixed side(D) to the left and right crib end.
using M6*80 Allen head bolts( 1 )&barrel nuts( 4 ).
See figure 6.
D
Step 5
Locate spring deck(G) with tabs.Be sure the
Position the tabs of spring deck to mount to
Figure 5
smooth side is placed upward( See figure 5).
selected position on the posts(See figure 5A).
Figure 5A
Figure 5B
Insert the M6*17 Allen head bolts( 3 ) through
the tabs and into the threaded inserts on the
posts. Tighten securely with Allen wrench( 5 )
(See figure 5B).
3
5
Allen head bolts
G
To Next Page
