Graco 244811 User Manual

23
Pump Assembly - Parts
24E735 (for use with Model 2525DD)
DESCRIPTION PART # QTY
KIT, REPAIR, VALVES 24E736 6
INCLUDES 1
KIT, REPAIR, PLUNGER 24E737 3
INCLUDES 2
KIT, REPAIR, OIL SEAL 24E738 3
INCLUDES 3
KIT, REPAIR, UNLOADER 24E739 1
INCLUDES 4
KIT, REPAIR, PACKINGS 24E740 3
INCLUDES 5, 6, 7, 8
KIT, REPAIR, CHEMICAL INJECTOR 24E741 1
INCLUDES 9, 10, 11
THERMAL RELIEF VALVE 117759 1
INCLUDES 12
FILTER, INLET 801112 1
INCLUDES 13
