Reassembly
309577K 21
FIG. 4. Reconnect Pump A
C
D
T
G
M
N
1
TI3765a-2
Flat side faces up.
1
Lubricate threads with ISO oil
or grease.
2
2
2
2
3
Pump top threads must be nearly
flush with bearing face (N).
3
U
P
Finger guard (P) not used on
Model E-30.
4
4
