Parts
309577K 23
Part 246830, E-20 and E-XP1; includes items 1-7, 9-28
Part 246831, E-XP2; includes items 1-7, 9-22, 24-28
Part 262647, A-25; includes items 1-7, 9-22, 24-28
Part 246832, E-30; includes items 1-22, 24-28 (shown)
* These parts are included in the Pump Repair Kits, which
may be purchased separately. Some parts in the kit may
not be used in your pump.
† These parts are included in the Wet-Cup Kits. Order the
correct kit for your pump from the table below. See page 26
for information on 246928 Reservoir Kit.
‡ This part is also available in the Intake Spring Kit 249770,
which may be purchased separately.
Ref. Part Description Qty.
1 240518 ROD, displacement; sst (246830) 1
240517 ROD, displacement; sst
(246831, 262647)
1
246689 ROD, displacement; sst (246832) 1
2 243346 CYLINDER, pump (246830) 1
243347 CYLINDER, pump
(246831, 262647)
1
245413 CYLINDER, pump (246832) 1
3* 108526 O-RING; PTFE (246830) 2
107098 O-RING; PTFE (246831, 262647) 2
108822 O-RING; PTFE (246832) 2
4 248209 SLEEVE, cylinder; sst (246830) 1
248210 SLEEVE, cylinder; sst
(246831, 262647)
1
248979 SLEEVE, cylinder; sst (246832) 1
5 195892 HOUSING, valve, intake (246830) 1
195894 HOUSING, valve, intake
(246831, 262647)
1
198219 HOUSING, valve, intake (246832) 1
7 239932 VALVE, piston (246830) 1
240150 VALVE, piston (246831, 262647) 1
240580 VALVE, piston (246832) 1
8*‡ 249770 SPRING, intake ball (246832 only) 1
9 239922 SEAT, intake; carbide (246830);
includes items 10 and 11
1
244199 SEAT, intake; carbide (246831,
262647); includes items 10 and 11
1
240918 SEAT, intake; carbide (246832);
includes items 10 and 11
1
10* 107079 O-RING; PTFE (246830) 1
108526 O-RING; PTFE (246831, 262647) 1
107098 O-RING; PTFE (246832) 1
11* 105445 BALL, intake; sst; 0.5 in. (13 mm)
(246830)
1
102972 BALL, intake; sst; 0.875 in. (22 mm)
(246831, 262647)
1
107167 BALL, intake; sst; 1 in. (25 mm)
(246832)
1
12 192624 GUIDE, ball (246830) 1
193027 GUIDE, ball (246831, 262647) 1
193391 GUIDE, ball (246832) 1
13* 117450 SEAL, u-cup, piston; UHMWPE
(246830)
1
117449 SEAL, u-cup, piston; UHMWPE
(246831, 262647)
1
117448 SEAL, u-cup, piston; UHMWPE
(246832)
1
14* 15B078 BUSHING, piston (246830) 1
15J197 BEARING, lower(246831, 262647) 1
15B079 BUSHING, piston (246832) 1
15* 156593 O-RING; BUNA-N (246830) 1
156633 O-RING; BUNA-N
(246831, 262647)
1
160325 O-RING; BUNA-N (246832) 1
16* 105444 BALL, piston; sst; 0.3125 in. (8 mm)
(246830)
1
101947 BALL, piston; sst; 0.375 in. (10 mm)
(246831, 262647)
1
107203 BALL, piston; sst; 0.5625 in. (14 mm)
(246832)
1
17* 15B075 BUSHING, rod (246830) 1
15B074 BUSHING, rod (246831, 262647) 1
15B076 BUSHING, rod (246832) 1
18 15J196 BUSHING, pump
(246831, 262647 only)
1
19† 15C569 NUT, packing (246830) 1
15C571 NUT, packing (246831, 262647) 1
15C573 NUT, packing (246832) 1
20* 117447 SEAL, u-cup, throat; UHMWPE
(246830)
1
117446 SEAL, u-cup, throat; UHMWPE
(246831, 262647)
1
117448 SEAL, u-cup, throat; UHMWPE
(246832)
1
22*† 118377 RING, retaining (246830) 1
118378 RING, retaining (246831, 262647) 1
118379 RING, retaining (246832) 1
23* 15B661 TOOL, installation, seal (246830
only); not shown; part of Repair Kit
246420
1
24*† 118381 O-RING; fluoroelastomer (246830) 1
107563 O-RING; fluoroelastomer
(246831, 262647)
1
118403 O-RING; fluoroelastomer (246832) 1
25† 118374 SPRING (246830) 1
118375 SPRING (246831, 262647) 1
118376 SPRING (246832) 1
26*† 118380 O-RING; fluoroelastomer (246830) 1
110955 O-RING; fluoroelastomer
(246831, 262647)
1
C20111 O-RING; fluoroelastomer (246832) 1
27*† 107563 O-RING; fluoroelastomer (246830) 1
103414 O-RING; fluoroelastomer
(246831, 262647)
1
111178 O-RING; fluoroelastomer (246832) 1
28† 15C570 PISTON, wet-cup, ISO (246830) 1
15C572 PISTON, wet-cup, ISO
(246831, 262647)
1
15C574 PISTON, wet-cup, ISO (246832) 1
Pump Part No. Pump Repair Kit Wet-Cup Kit
246830 246420 246962
246831, 262647 15C851 246963
246832 15C852 246964
