Technical Specifications
3A5414A 11
Technical Specifications
Dimensions
Pulse HUB
US Metric
Weight HUB with Power Adapter 1.0 lbs 454 g
Operating Temperature Range -4°F to 158°F -20°C to 70°C
Power Supply
To Power Supply 100 - 240 VAC line voltage
50-60 Hz 0.05A
To HUB 5 Vdc (0.5 amps typ)
RF Frequency Band 2400 - 2483.5 MHz
Maximum RF Transmit Power
Model 24Z978 63 mW (18 dBm)
Model 25D454 6.3 mW (8 dBm)
