Pressure Relief Procedure
4 3A5265A
Option 1
Flange bearings in both motor and drive housing:
Option 2
Flange bearing in motor, needle bearing in drive housing:
ti31601a
108131
Thrust Bearing
24X020
Crankshaft
Repair Kit
DRIVE
HOUSING
SIDE
MOTOR
SIDE
249194 Gear
ti31602a
108131
Thrust Bearing
DRIVE
HOUSING
SIDE
MOTOR
SIDE
116079 Copper
Thrust Bearing
249194 Gear
24X020
Crankshaft
Repair Kit
