Graco Booster Seat - Securing Child with Shoulder Belt Positioning Clip; Purpose of Positioning Clip; Attaching the Clip

30
Securing Child in Vehicle with
Shoulder Belt Positioning Clip
The shoulder belt MUST lie
across child’s shoulders in
red zone as shown.
If shoulder belt lies outside
this zone, the shoulder belt
positioning clip MUST be
used.
To attach clip to booster
seat:
1. The shoulder belt positioning clip MUST be
attached onto the horizontal bar in the center of the
base. Insert the loop end of strap around horizontal bar
on rear of seat as shown in .
1
1
