309642 5
Parts List
Ref.
No. Part No. Description Qty.
31 244162 KIT, Cleanestt repair 1
includes parts 31a–31k
31a SEAT, valve 1
31b GASKET 1
31c RETAINER, ball 1
31d DAMPENER, spring 1
31e SPRING, compression 1
31f GUIDE, spring 1
31g SEAL, u–cup 1
31h PACKING, o–ring 1
31i RETAINER, u–cup 1
31j CAP, end, u–cup 1
31k KNOB, valve 1
33 162863 GASKET, non–metallic 2
34 120190 PACKING, o–ring 2
35 244363 KIT, swivel repair 1
35a 244663 SWIVEL, inlet assembly 1
35b 120189 NUT, cap 1
35c 107505 PACKING, o–ring 2
35d 109576 PACKING, o–ring 1
36 245687 KIT, valve body 1
36a STUD, manifold 1
36b GASKET, nylon 1
36c VALVE, outlet 1
LTX517 RAC X Latex SWITCHTIP
(not shown) 1
246215 RAC X HandTite Guard
(not shown) 1
TECHNICAL DATA
Wetted parts Aluminum, Tungsten Carbide, PTFE. . . . . . . . . .
Stainless Steel
Fluid inlet/outlet 7/8–14 UNF. . . . . . . . . . . . . . . . . . . . . . . . . . . .
Maximum working pressure 3600 psi (24.8 MPa, 248 bar). . .
TO PLACE AN ORDER, contact your Graco distribu-
tor, or call this number to identify the distributor closest
to you: 1–800–690–2894 Toll Free
