308-088
"# # !"$"
Includes items 1 to 83 as listed below
1 107-156 SCREW, mach, pan hd, 6-32 x 5/8" 6
2 181-062 COVER,
drive housing 1
3 110-037 SCREW,
mach, pan hd, 10-24 x 1/2" 4
5 183-281 DRAIN TUBE 1
8 224-308 DRIVE ASSEMBLY
includes replacement items 8a - 8f 1
8a 104-008 .LOCKWASHER,
spring, 5/16" 2
8b 106-115 .LOCKWASHER,
spring, 3/8" 4
8c 100-659 .CAPSCREW
, soc hd, 3/8-16 x 1" 4
8d 100-657 .CAPSCREW,
soc hd, 5/16-18 x 2" 2
8e 105-510 .LOCKWASHER,
spring, 1/4" 4
8f 100-644 .CAPSCREW,
soc hd, 1/4-20 x 3/4" 4
11 106-228 TEE,
street, 1/4 npt (m x f x f) 1
13 224-307 MOTOR,
electric, dual voltage,0.75 HP
includes replaceable items 13a-13g
1
13a 102-799 .TERMINAL,
wire, ring see page 24 1
13b 185-954{ .LABEL,
DANGER 1
13c 107-263 .TERMINAL,
wire, female, slip-on
see page 24 1
13d 106-077* .CAPACITOR,
motor, includes resistor1
13e 181-118{ .LABEL 1
13f 110-938* .START SWITCH
not shown: inside motor 1
13g 224-306 .ADAPTER, harness
used only with replacement motor 1
14 222-002 Black Max" SPRAY GUN
See manual 307-821 for parts. 1
16 106-075 SCREW,
mach, oval hd, 10-24 x 1/2" 4
17 183-998 COVER,
pressure control 1
18 222-227 PRESSURE CONTROL ASSEMBLY
see parts on page 24 1
19 177-762{ LABEL,
WARNING 1
23 223-740 FRAME,
sprayer 1
24 105-521 PLUG,
tubing 2
25 178-342 SPRING CLIP 2
26 223-748 HOSE
, nylon, 1/4" ID, cpld 1/4
npsm(fbe), 22" (559 mm),
spring guard full length
1
27 223-541 HOSE,
nylon, 1/4" ID, cpld 1/4
npsm(fbe), 50 ft (15 m) long,
spring guards both ends
1
28 102-932 CONNECTOR,
conduit, 90_,
1/2 npt x 1/2 conduit 1
29 218-215 DISPLACEMENT PUMP
see parts on page 23 1
30 162-453 NIPPLE,
1/4 npsm x 1/4 npt 3
31 176-762 NUT,
hex, 1 1/2-18 1
32 065-099 CONDUIT,
electrical 102 mm
33 206-994 THROAT SEAL LIQUID,
8 oz not shown 1
34 170-113 TUBE, suction 1
35 221-077 PRESSURE DRAIN VALVE 1
36 108-982 CONNECTOR,
tube, 1/8 npt (m) x
3/8" dia. tube
1
37 178-034{ TAG,
WARNING 1
38 100-057 CAPSCREW,
hex hd, 5/16-18 x 3/4" 4
39 100-214 LOCKWASHER,
spring, 5/16" 6
40 100-188 NUT,
heavy, hex, 5/16-18 4
42 107-194 WASHER,
flat, 5/16" 4
50 104-008 LOCKWASHER,
spring, 5/16" 2
51 105-509 CAPSCREW, soc hd, 5/16-18 x 7/8" 2
52 186-369 BRACKET,
mounting, pres. control 1
54 215-904 CONNECTING ROD 1
60 177-670 GEAR,
pinion 1
61 105-680 PIN,
spring, straight, .167" dia. x 1.0" 1
63 176-818 PIN,
str, hdls, .3125" dia. x 1.023" 2
64 176-824 COUPLING,
pump 1
65 176-817 SPRING,
retaining, 1.040" ID 2
66 215-903 BEARING HOUSING 1
68 100-001 CAPSCREW,
hex hd, 5/16-18 x 5/8" 2
69 100-840 ELBOW,
street, 1/4 npt (f x m) 1
71 183-285 NIPPLE 1
72 181-073 STRAINER 1
73 220-251 TIP GUARD 1
74 163-415 SPRAY TIP, Size 415
See manual 306-686 1
77 187-028 TUBE HOLDER 1
78 104-966 SCREW, M6 x 1.0 x 16 2
79 108-050 LOCKWASHER, M6 2
80 103-927 HOSE CLAMP 2
81 221-020 SWIVEL UNION, 90_ 1
82 176-920 SUCTION HOSE 1
83 103-473 TIE STRAP 2
*Recommendedspare parts.Keepon hand toreducedown time.
{Extra warning labels are available at no charge.
To Next Page
