Technical Data
307427ZAF 37
Technical Data
Category Data
Recommended air operating range Model 226951: 0.3 to 0.4 MPa, 3 to 4.2 bar (0 to 60 psi)
All Other Models: 0.3 to 1.2 MPa, 3 to 12 bar (40 to 180
psi)
Air consumption
Approx. 0.05 m
3
/min (1.5 cfm/gal) at 4 liters/min (1 gpm)
at 0.5 MPa, 5.6 bar (80 psi) input
Maximum recommended pump speed 100 cycles/min: 15.1 liters/min (4 gpm)
Air inlet size 1/4 npt(f)
Fluid inlet size 1-1/2 npt(f)
Fluid outlet size 3/4 npt(f)
Maximum Operating Temperature 120°F (49°C)
Sound Pressure Level at 100 psi (0.7 MPa, 7 bar): 72 dB(A)
at 65 psi (0.45 MPa, 4.5 bar): 70 dB(A)
Sound Power Level at 100 psi (0.7 MPa, 7 bar): 82 dB(A)
at 65 psi (0.45 MPa, 4.5 bar): 81 dB(A)
Weight Stubby Pump: 11 lbs (5 kg)
Drum Pump: 20 lbs (9 kg)
Wetted parts Models 226940, 226943, 237130, and 237133:
Carbon Steel, 303, 304 and 316 Stainless Steel,
Leather, Cadmium-Plated Ductile Iron, Chrome and
Zinc-Plated Steel, PTFE, fluoroelastomer
Models 226941, 226944, and 686445: Carbon Steel,
303, 304 and 316 Stainless Steel, Cadmium-Plated
Ductile Iron, Chrome and Zinc-Plated Steel, PTFE,
fluoroelastomer, Polyethylene
Model 237131 and 237134: Carbon Steel, 303, 304 and
316 Stainless Steel, Cadmium-Plated Ductile Iron,
Chrome and Zinc-Plated Steel, PTFE, fluoroelastomer
Models 226942 and 226945: 303, 304 and 316 Stainless
Steel, Chrome, PTFE, fluoroelastomer, Polyethylene
Models 237129 and 237132: 303, 304 and 316 Stainless
Steel, Chrome, PTFE, fluoroelastomer, Polyethylene
Models 226947, 226948, and 226951: 303, 304 and 316
Stainless Steel, Buna-N, Cadmium-Plated Ductile Iron,
Chrome and Zinc-Plated Steel, PTFE, fluoroelastomer,
Polyethylene
Models 226952 and 226953: 303, 304 and 316 Stainless
Steel, Chrome, PTFE, Rubber
