Graco MARK V

Technical Data
34 311344B
Technical Data
Basic Sprayer Wetted Parts..............................
zinc- and nickel-plated carbon steel, nylon, stainless steel, PTFE, Acetel, leather, UHMWPE, aluminum, tungsten
carbide, PEEK, brass
Noise Level
Sound power ............................................... 91 dBa*
Sound pressure ........................................... 82 dBa*
*per ISO 3744; measured at 3.1 feet (1 m)
Dimensions
Model
100 -
120V, A,
Hz
220 -
240V
XXX, A,
Hz
Generator
Minimum W
Motor
HP (W)
Cycles per
gallon
(liter)
Maximum
Delivery
gpm (lpm)
Maximum Tip
Size
Fluid
Outlet
npsm1 Gun
2
Guns
695
14,
50/60
9,
50/60
5000 1.75
(1300)
243 (64) 0.75 (2.8) 0.027 N/A 1/4 in
795
15,
50/60
10,
50/60
5000 2.00
(1490)
195 (52) 0.95 (3.6) 0.031 0.021 1/4 in
1095
15,
50/60
10,
50/60
5000 2.20
(1640)
123 (33) 1.1 (4.1) 0.033 0.023 1/4 in
Mark V
N/A 10,
50/60
5000 2.20
(1640)
110 (29) 1.2 (4.3) 0.035 0.023 3/8 in
1595
20/15,
50/60
N/A 5000 2.5
(1860)
110 (29) 1.25 (4.7) 0.037 0.025 1/4 in
Mark V
20/15,
50/60
N/A 5000 2.5
(1860)
110 (29) 1.25 (4.7) 0.037 0.025 3/8 in
Model
Weight lb (kg) Height in (cm)
Length
in (cm)
Width
in (cm)Lo-Boy Hi-Boy Lo-Boy Hi-Boy
695 94
(43)
94
(43)
26.5 (67.3) Handle down,
38.8 (98.6) Handle up
28.5 (72.4) Handle down,
38.75 (98.4) Handle up
25.75
(65.4)
20.5
(52.1)
795 98
(45)
98
(45)
26.5 (67.3) Handle down,
38.8 (98.6) Handle up
28.5 (72.4) Handle down,
38.75 (98.4) Handle up
25
(63.5)
20.5
(52.1)
1095 N/A 120
(55)
N/A 29.5 (74.9) Handle down,
38.5 (97.8) Handle up
26
(66)
22.5
(57.2)
1595 N/A 125
(57)
N/A 29.5 (74.9) Handle down,
38.5 (97.8) Handle up
26
(66)
22.5
(57.2)
Mark V N/A 130
(59)
N/A 29.5 (74.9) Handle down,
38.5 (97.8) Handle up
26
(66)
22.5
(57.2)
