Dynamic Dosing Restrictor Selection Graphs
64 3A0869C
FIG. 57. Dynamic Dosing Performance (10:1 Ratio, 90 centipoise fluid, 100 psi A side pressure)
0
500 1000 1500 2000 30002500 35000
Flow Rate (cc/min)
Differential Pressure between A and B
psi
(bar, MPa)
800
(55, 5.5)
700
(48, 4.8)
600
(41, 4.1)
500
(34, 3.4)
400
(28, 2.8)
300
(21, 2.1)
200
(14, 1.4)
4000
100
(7, 0.7)
#2 Restrictor
#3 Restrictor
#4 Restrictor
#7 Restrictor
Key
Detail View
200
(14, 1.4)
500 1000
100
(7, 0.7)
50
(3.4, 0.34)
150
(10, 1.0)
0
0
