Dynamic Dosing Restrictor Selection Graphs
66 3A0869C
FIG. 59. Dynamic Dosing Performance (30:1 Ratio, 90 centipoise fluid, 100 psi A side pressure)
0
500 1000 1500 2000 30002500 35000
Flow Rate (cc/min)
Differential Pressure between A and B
psi
(bar, MPa)
160
(11, 1.1)
140
9.7, 0.9)
120
8.3, 0.8)
100
(7, 0.7)
80
(5.5, 0.55)
60
(4.1, 0.41)
40
(2.8, 0.28)
4000
20
(1.4, 0.14)
180
(12.4, 1.2
200
(14, 1.4
#2 Restrictor
#3 Restrictor
#4 Restrictor
#7 Restrictor
Key
Detail View
30
(2.1, 0.21)
500 1000
40
(2.8, 0.28)
20
(1.4, 0.14)
10
(0.7, 0.07)
0
0
