Graco SnugRide Click Connect 35 User Manual

30
1. MAKE SURE vehicle is on level ground. Make sure to check your
vehicle owner's manual for LATCH seating
positions.
2. For ease of installation, press button to extend
LATCH to its MAXIMUM LENGTH

.
3. Position base in vehicle seat as shown.
4. Make sure LATCH is through vehicle/LATCH
belt path normally used for vehicle seat belt.

.
Belt must lie flat and not be twisted.
5. Attach connectors to vehicle lower anchors.
Pull firmly on connectors to be sure they
are attached .
6. Tighten LATCH by pushing down hard on
base and pulling the adjustment belt back
through belt path .


6.3 Using LATCH to Install Base


CLICK!

Graco SnugRide Click Connect 35 Specifications

General

Type	Infant Car Seat
Child Weight Capacity	4-35 lbs
Weight Limit	35 lbs
Removable Seat Cover	Yes
Height Limit	32 inches
Compatibility	Graco Click Connect Strollers
Safety Features	EPS Energy Absorbing Foam
Canopy	Adjustable
