Vehicle
Information
10
104
How to Lock Your Lap and Shoulder Vehicle Seat Belt
Sliding Latch Plate and Switchable Retractor
A latchplate that slides freely on the belt webbing
and cannot, by itself, hold the belt snug around a
car seat.
When installing the car seat, route the vehicle seat
belt through the proper belt path and buckle it in.
Slowly pull the shoulder belt all the way out
to switch it to locking mode. Then, as you pull
the vehicle seat belt tight, feed all the slack back
into the retractor.
Grab the sides of the seat at the belt path and
slide the seat side-to-side and front-to-back. The
seat should not move more than 1” (2.5 cm).
Note: With the vehicle seat belt in this locking
mode, all the tension is upwards in the shoulder
belt. This may start to tilt your car seat sideways
when rear-facing. If this happens, use a locking
clip instead of this switching the retractor. See
Sliding Latch Plate and ELR Retractor.
Note: When using the
lock-off, you do not need
to switch the retractor.
The lock-off locks the
seat belt.
NWL0001148417C True3Fit LX USA ENG R04 (8BZ20).indd 104NWL0001148417C True3Fit LX USA ENG R04 (8BZ20).indd 104 9/18/20 11:51 AM9/18/20 11:51 AM
