Parts
68 3A0420ZAF
Replacement safety labels, tags, and cards are available at no cost.
48 101566 NUT, lock 2 2 2 2
49 15U654 LABEL, identification, A/B 1 1 1 1
50 555357 SCREW, 1/4-20 x 0.5 in. 4 4 4 4
51 124450 CLAMP, spring 2
2
52 124293 BOLT, u-bolt 1 1 1 1
53 124259 BRAKE, plunger clamp 1 1 1 1
54 124291 PIN, spring 2 2 2 2
55 24E872 BRACKET, hopper 2
2
56 262479 HOPPER, blue 1 1
57 262480 HOPPER, green 1 1
58 116704 ADAPTER, fitting 2 2
59 14V421 TUBE, recirculation 2 2
60 H52506 HOSE, circulation, 6 ft 2 2
H52510 HOSE, circulation, 10 ft 2 2
61 16D376 FITTING, intake, with plug 2
2
62 111192 SCREW, serrated flange head, 3/8-16 4 4
65 262482 STRAINER, hopper, 7 gallon 2 2
66 15T468 LABEL, warning 2 2
67 16E336 GUIDE, quick start 1 1 1 1
68 114958 STRAP, tie 10 10 10 10
69 16F615 TOOL, wrench, Xtreme 1 1 1 1
70 16F359 LABEL, warning 1 1 1 1
71 16F536 LABEL, arrow 1 1 1 1
72 262392 PUMP, solvent (see pg 74 for details)
1 1
73 104984 FITTING, tee, 1/4 in. npt
1 1
74 156971 FITTING, nipple, 1/4 in. npt
1 1
75 H42506 HOSE, 4500 psi, 1/4 in. x 6 ft
1 1
76 214037 VALVE, ball, 1/4 in.
1 1
77 205447 COUPLING, hose
1 1
78 061132 HOSE, primer
1 1
79 24F126 MODULE, air controls
1 1
80 16F537 HOSE, air line, 6 ft
1 1
83 H75005 HOSE (heater to manifold)
2 2
84 166590 FITTING, elbow
2 2
85 245863 HEATER, 240V, hazardous locations
2 2
89 16G819 TOOL, wrench, Xtreme 1 1 1 1
90 16J688 PLUG, hole 1
1
92 126786 TOOL, restrictor 1 1 1 1
Ref. Part Description
Quantity
XP50-h XP70-h
284xx4
284xx5
284xx6
284xx7
To Next Page
