Manual Universal Slicing Machine H 9
© Gebr. Graef GmbH & Co. KG / 02
EN
27
Requirements for the installation location
For safe and flawless operation of the unit, the place of loca-
tion must meet these prerequisites:
■ The unit must be set up on a firm, flat, level, and non-slip
base that has sufficient load bearing capacity.
■ Select the place of location so that children cannot reach
the sharp blade in the unit.
Setup and Functioning
Overview
1) Handle
2) Slicing thickness
control
3) Stainless steel car-
riage
4) Serrated blade
5) Carriage guide
profile
1
2
3
4
5
