Operation
19
3.2.1.3. Cross shingling
The cross shingling function is for placing the individual slices in rows parallel to the
chain frame. The number of rows can be set using the “X“ button. Up to 4 rows are
possible with the standard programme. When making preparations, it is recommended to
set the slice counter to “000”. The machine then fans multiple layers on top of each
other.
If rows are to be generated on portioning units (foils, PE trays, foam trays, trays etc.), you
can enter the outer dimensions of the portioning units L x W for central placing. (Option:
the machine then uses the calibre recognition option to calculate the best placing point).
Example:
3.2.1.4. Circular shingling
Circular shingling enables the slices to be placed in a circular pattern.
The diameter of the circle can be altered by adjusting the tray dimensions. In this way,
oval placing patterns are also possible.
Example:
Select function
“Cross shingling”
Select function
“Circular shingling”
