MAINTENANCE
51
5 Maintenance
5.1.Sharpening the Blade
WARNING!
Rotating blade can sever fingers! Only sharpen the blade with the sharpener
provided. The sharpener has been adjusted for this machine and must be used
for this machine only.
The machine number and the number on the sharpening device are identical.
The blade may only be sharpened by personnel who have been trained to do so.
5.1.1. Description of the Blade Sharpener
Adjusting wheel
Scale:
x 0 = attaching position
x 1 = sharpening position
x 2 = honing position
Blade sharpener housing
Protective cover
Clamp arms
Knurled screw
Honing stone
Sharpening stone
Blade sharpener mounting
