Operation
39
Example: Programming PLU “10“
| singling, 2 rows of 9 slices, fan distance 20, row distance 100, 1 portion, slicing
thickness 1.8 mm, slices per minute 50 (=strokes per min)
PLU 10
mode | shingling
quantity 2
slices 9
portion 1
X start 45
Y start 20
dist row 100
dist slice 22
str/min 50
Thickn 18
Pause 0
Tra
y
X start
Y start
Slice
distance
Row
distance
Slices
X number of rows/
stacks
