1. Assemble the cuff, then insert the tube plug into the air connector.
Before the measurement, take 3~5 deep breaths and relax. Don’t talk
or move your arm;
2. Press button ‘ ’, and all symbols will appear on display in 2 seconds
then ‘0 mmHg’ will appear on the screen. The pump begins to inflate
with display showing the pressure reading. Generally the pressure will
reach 190 mmHg as shown in Fig.5;
3. The pump stops inflating and the pressure begins to decrease
gradually, during which the user’s blood pressure and pulse will be
calculated as shown in Fig.6;
IRREGULAR HEARTBEAT DETECTION
When the device detects the irregular heartbeat or any excessive body
movement during measurement, ‘ ’ icon will flash on the screen as
shown in Fig.7.
WARNING: Contact your physician if
you see the ‘ ’ indicator frequently.
CARRYING OUT A MEASUREMENT
Fig.6
Fig.7
Fig.5
11
