32
Compact 210/310/410 with castors or legs:
The cabinet is tilted slightly backward, and the front part of the pallet can be removed.
Then the cabinet is tilted slightly forward, and the rear part can be removed.
This task requires at least 2 persons.
Fig. 2
If the cabinet has been transported in horizontal position it must stand
upright at least 2 hours before it is started to allow the oil from the
compressor to run back.
