EN OPERATING INSTRUCTIONS

IMC 20678-90 X

Main Page

Questions and Answers

C
Cheyenne FrazierAug 5, 2025
Why Gram Oven does not start?
- C
  Carolyn MurphyAug 5, 2025
  Your Gram Oven might not start due to a few reasons. First, check if the power cord is properly plugged into the socket; try pulling the plug and reinserting it after 10 seconds. Second, a blown fuse or tripped circuit breaker could be the issue; replace the fuse or turn the circuit breaker on (any repairs by manufacturer service only). Lastly, there might be a problem with the power outlet itself; test the outlet by plugging in another appliance.

The Gram IMC 20678-90 X is a built-in microwave oven designed for household use, offering a range of cooking functions including microwave, grill, and various combi modes, as well as automatic programs and defrosting options.

Function Description

The appliance provides versatile cooking capabilities:

Microwave Function: Ideal for cooking and heating vegetables, potatoes, rice, fish, and meat.
Forced Air Circulation (Hot Air): Allows for cooking meals similar to a conventional oven. The microwave function is not active in this mode. Preheating the oven is recommended.
Grill Function: Particularly useful for cooking thin cuts of meat and fish. It offers three power levels.
Roaster with Fan (Grill with Fan): Combines grilling with fan circulation for even cooking and simultaneous browning of dishes.
Lower Heater with Forced Air Circulation: Suitable for baking dishes such as pizza, moist cake, fruit cake, and sponge cake.
Combi Modes:
- Microwave + Hot Air: For quick baking of dishes.
- Microwave + Grill with Fan: Useful for preparing small cuts of meat, fish, or vegetables, and for browning the skin.
- Microwave + Lower Heater + Forced Air Circulation: For dishes requiring rapid cooking and heating.
- Microwave + Grill: For rapid cooking and simultaneous browning of the dish skin (also baked dishes). Microwaves cook the food while the grill bakes it.
Automatic Programs (P01-P13): Thirteen predefined programs for various types of food, where power and temperature are set automatically based on food type and weight. Some programs include a "keep warm" step.
Defrosting by Weight (d01-d03): Three predefined programs for defrosting meat or vegetables based on their weight.
Defrosting by Time: Allows the user to set a specific defrosting time.
Keep Warm Function: Can be activated after selecting forced air circulation, air circulation, combi (microwave + forced air circulation), or combi (microwave + air circulation) functions. The microwave function is off during this mode.
Child Lock: A safety feature that locks the controls to prevent accidental operation, activated by pressing and holding a button for 3 seconds in standby mode.

Important Technical Specifications

Model: IMC 20678-90 X
Power Supply: 230V~/50Hz
Operating Frequency: 2450 MHz
Noise Level: 63 dB(A) re 1pW
Power Consumption: 3350 W
Nominal Output Power of Microwaves: 900 W
Nominal Output Power of Grill: 1750 W
Oven Capacity: 44 liters
Turntable Diameter: 360 mm
External Dimensions (H x W x D): 455.5 x 595 x 568.5 mm
Appliance Type: Built-in
Net Weight: 41 kg

Usage Features

Clock Setting: The appliance features a digital clock that can be set to display time between 00:00 and 23:59.
Microwave Power Levels: Offers various power levels (100W, 300W, 450W, 700W, 900W) for different cooking needs, with maximum cooking times varying by power level.
Temperature Control: For functions like forced air circulation and grill, temperatures can be set within a range (e.g., 50°C to 230°C).
Cooking Time: Cooking times can be set from 10 minutes up to 5 hours for certain functions, and up to 90 minutes for others.
Cookware Compatibility: The manual provides detailed guidance on suitable and unsuitable cookware materials for microwave, grill, and combi modes, including specific instructions for aluminum foil and containers. Heat-resistant glass, ceramics, and microwave-safe plastic utensils are generally recommended for microwave use. Metal containers are suitable for grill and combi modes (with exceptions).
Turntable Installation: The turntable and rotating trolley must always be used during cooking. Food should be placed directly on the turntable.
Safety Interlocks: The oven is equipped with safety interlocks to prevent operation with the door open.
Grounding: The appliance must be properly grounded to reduce the risk of electric shock.
Ventilation: Proper ventilation is crucial for the oven's operation and should not be blocked.

Maintenance Features

Regular Cleaning: The oven must be cleaned regularly to remove food deposits and leftovers. Neglecting this can damage the surface and create dangerous situations.
Interior Cleaning: After use, the inside of the microwave oven should be cleaned with a damp cloth. For stubborn stains, half a lemon in a bowl with 300 ml of water can be heated at 100% power for 10 minutes, then wiped with a soft, dry cloth.
Accessory Cleaning: Accessories should be cleaned in soapy water.
Door and Seals: The door frame, seal, and adjacent elements should be cleaned gently with a damp cloth and mild soap or detergent. Abrasive cleaners or sharp metal washers should not be used on the glass door.
Power Cord Check: Regularly check the oven and its power cord for damage. If damaged, it must be replaced by a qualified person.
Troubleshooting Guide: The manual includes a troubleshooting section to address common issues such as the oven not starting, not heating, or the turntable making noise.
Manufacturer's Declaration: The product complies with European directives including Low Voltage (2014/35/UE), Electromagnetic Compatibility (2014/30/UE), Eco-design (2009/125/UE), and RoHS (2011/65/UE), and bears the CE symbol.
Disposal: At the end of its useful life, the appliance should be taken to an electronic waste collection and recycling point, not disposed of with normal municipal waste. Packaging materials are 100% recyclable.
