P a g e | 16

GDS3710 Input/output Alarms

Configuration Guide

Motion Detection

Users can select a specific region to trigger the alarm using motion detection.

Figure 15: Region Config

Table 3: Motion Detection

Enable Motion Detection

Click on the check box to enable Motion Detection.

Region Config

Click to enter the Region Config menu.

Quit Config

Click to exit the Region Config menu.

Clear Selected Region

Select a zone on the screen then click on Clear to delete the region.

Sensitivity

Region sensitivity (value between 0-100%).

Select Alarm Schedule

Select the Schedule programmed.

Select Alarm Action Profile

Select the programmed Alarm Action.
