Using the GXP1400/1405
GETTING FAMILIAR WITH THE LCD
GXP1400/1405 has a dynamic and customizable screen. The screen displays differently depending on
whether the phone is idle or in use (active screen).
Table 7: LCD Display Definition
Display Item Definitions
DATE AND TIME
Displays the current date and time. It can be synchronized with Internet time
servers
LOGO NAME
Displays company logo name. This logo name can be customized via xml screen
customization. The maximum size for logo name is 22 characters in English
NETWORK
STATUS
Shows the status of network in the middle of the screen. It will indicate whether
the network is down or starting
STATUS BAR
Shows the status of the phone, using icons as shown in the next table
SOFTKEYS
The softkeys are context sensitive and will change depending on the status of
the phone. Typical functions assigned to soft-buttons are:
• FORWARD ALL Unconditionally forwards the phone line to another
phone
• MISSED CALL This option shows unanswered calls to this phone.
• NEXTSCR Press this button to toggle between idle screen, weather
and IP Address.
• REDIAL Redials the last dialed-out number
• END CALL Hangs up the call
Table 8: LCD Icons
LCD Icons Descriptions
SIP Registration Status Icon:
Solid – connected to SIP Server/IP address received
SIP Registration Status Icon:
Blank – SIP Proxy/Server not registered
Handset Status Icon:
OFF - handset on-hook ON - handset off-hook
Speaker Phone Status Icon:
OFF - speakerphone off ON - speakerphone on
Headset Status Icon:
OFF - headset off ON - headset on
