FIRMWARE VERSION 1.0.0.17 GXP2140/GXP2160 USER MANUAL Page 12 of 79
User and administrator level passwords, MD5 and MD5-sess based
authentication, AES based secure configuration file, SRTP, TLS, 802.1x media
access control
English, Arabic, Chinese, Croatian, Czech, Dutch, German, French, Hebrew,
Hungarian, Italian, Japanese, Korean, Polish, Portuguese, Russian, Slovenia,
Spanish, Turkish
Firmware upgrade via TFTP/HTTP/HTTPS, mass provisioning using TR-069 or
encrypted XML configuration file
Power & Green
Energy Efficiency
Universal power adapter included:
Input:100-240V ; Output: +12V, 1A ;
Integrated Power-over-Ethernet (802.3af)
Max power consumption: 6W (without GXP2200EXT), 10W(with 4 cascaded
GXP2200EXTs )
Dimention: 222mm (W) x 210mm (L) x 93mm (H); Unit weight: 0.98kg; Package
weight: 1.55kg
32-104℉ / 0～40℃, 10-90% (non- condensing)
GXP2140 phone, handset with cord, base stand, universal power supply, network
cable, Quick Start Guide
FCC Part15 Class B, EN55022 ClassB, EN61000-3-2, EN61000-3-3, EN55024,
EN60950-1, AS/NZS CISPR22 Class B
Table 4: GXP2160 TECHNICAL SPECIFICATIONS
SIP RFC3261, TCP/IP/UDP, RTP/RTCP, HTTP/HTTPS, ARP, ICMP, DNS (A
record, SRV, NAPTR), DHCP, PPPoE, SSH, TFTP, NTP, STUN, SIMPLE, LLDP,
LDAP, TR-069, 802.1x, TLS, SRTP, IPv6
Dual switched auto-sensing 10/100/1000 Mbps Gigabit Ethernet ports with
integrated PoE
4.3 inch (480x272) TFT color LCD
6 line keys with up to 6 SIP accounts, 24 speed-dial/BLF extension keys with
dual-color LED, 5 programmable context sensitive softkeys, 5 navigation/menu
keys, 11 dedicated function keys for : MESSAGE (with LED indicator),
PHONEBOOK, TRANSFER, CONFERENCE, HOLD, HEADSET, MUTE,
SEND/REDIAL, SPEAKERPHONE, VOL+, VOL-
Support for G.729A/B, G.711µ/a-law, G.726, G.722 (wide-band), and in-band and
out-of-band DTMF (in audio, RFC2833, SIP INFO)
RJ9 headset jack (allowing EHS with Plantronics headsets), USB, extension
module port
