Grandstream Networks GXP2160 Quick Installation Guide

3 4
CONNECTING THE PHONE:
PHONE SETUP:
PC Port LAN Port Power Headset Port Handset Port
Installing the Phone (Phone Stand):
For installing the phone on the table with the phone st and, attach the phone stand
to the bottom o the phone where there is a slot or the phone stand (upper part,
bottom part) .
Installing the Phone (Wall Mount):
1. Attach the wall mount to the slot on the back o the phone.
2. Attach the phone to the wall via the wall mount hole.
3. Pull out the tab rom the handset cradle (See gure below).
4. Rotate the tab and plug it back into the slot with the extens ion up to hold the
handset while the phone is mounted on the wall (See gure below).
Tab with extension up
Handset rest
Tab with extension down
Slots for the
wall mount and
phone stand
USB Port
Installing BLF Paper Label:
1. Install the paper label under the plastic notches on the phone and gently lay the
paper down on the phone surace.
2. Install the plastic cover over the paper label by ins erting the cover unde r the
plastic notches on the phone.
Label
Cover
GRANDSTREAM GXP2160

Grandstream Networks GXP2160 Specifications

General

Brand	Grandstream Networks
Model	GXP2160
Category	IP Phone
Language	English
