Base DN
Determines the LDAP search base. This is the location in the directory where the search is requested
to begin.
Example:dc=grandstream, dc=comou=Boston, dc=grandstream, dc=com
Username
Configures the bind “Username” for querying LDAP servers. Some LDAP servers allow anonymous
binds in which case the setting can be left blank.
Password
Specifies the bind “Password” for querying LDAP servers. The field can be left blank if the LDAP server
allows anonymous binds.
LDAP Name
Attributes
Configures the “name” attributes of each record which are returned in the LDAP search result. This
field allows the users to configure multiple space separated name attributes.
Example:cn sn description
LDAP Number
Attributes
Configures the “number” attributes of each record which are returned in the LDAP search result. This
field allows the users to configure multiple space separated number attributes.
Example: telephoneNumber, telephoneNumber Mobile
LDAP Mail
Attributes
Determines the “mail” attributes of each record which are returned in the LDAP search result.
Example: mail
LDAP Name Filter
Configures the filter used for name lookups.
Examples:
(|(cn=%)(sn=%)) returns all records which has the “cn” or “sn” field starting
with the entered prefix
(!(sn=%)) returns all the records which do not have the “sn” field starting
with the entered prefix
;(&(cn=%) (telephoneNumber=*)) returns all the records with the “cn” field starting with the entered
prefix and “telephoneNumber” field set.
LDAP Number
Filter
Defines the filter used for number lookups.
Examples:
(|(telephoneNumber=%)(Mobile=%)
returns all records which has the “telephoneNumber” or “Mobile” field starting with the entered
prefix;
(&(telephoneNumber=%) (cn=*))
returns all the records with the “telephoneNumber” field starting with the entered prefix and “cn”
field set.
LDAP Mail Filter
Determines the filter used for mail lookups.
Example: (mail=%)
Search Field Filter
Configures to filter according to which fields when searching on LDAP. Users can choose between
‘Name Filter’, ‘Number Filter’, ‘Mail Filter’ or ‘All Filter’.
The default setting is “All Filter”.
LDAP Displaying
Name Attributes
Configures the entry information to be shown on phone’s LCD. Up to 3 fields can be displayed.
Example: %cn %sn %telephoneNumber
Max Hits
Specifies the maximum number of results to be returned by the LDAP server. If set to 0, server will
return all search results.
Default setting is 50.
